Signal Conditioning and Data Acquisition Systems

Signal Conditioning and Data Acquisition Systems

We are pleased to provide the brief information on the comprehensive solutions for High end Signal Conditioning and Data Acquisition Systems integrated and provided through our exclusive Technology Alliance Partnership (TAP) with M/s Pacific Instruments, USA. As the TAP and authorized System Integrators, Offshore Developers and Custom Engineering Centre for Pacific, Symmetric has provided solutions for Rocket Engine hot test stands, Vibration Data Acquisition test setup, Air Turbine Starter Rig, Propellant evaluation Static Test firing setups, Weapons evaluation and Life cycle management, Rocket Stage separation tests etc to name a few. We welcome your attention and look forward to talk to you on your specific requirements.

Product Categories

Signal Conditioning Systems: Series 6100

Feature

  • High Performance Conditioning with dual analog outputs per channel
  • Choice of 2 or 4 channels per module
  • Sensors: Static & Dynamic Strain, RTD, Charge, IEPE, Voltage, TC & more.
  • Programmable short circuit protected voltage & current excitation sources, Programmable filters.
  • Programmable Gains up to 10,000 and 100KHz (-3dB) Wide bandwidth
  • -120dB CMRR at 300V CMV, Buffered, Short Circuit protected Analog Outputs settable as filtered / Wideband
  • Turnkey & API Software

Data Acquisition Systems Series 6000

Feature

  • Completely Modular - 2 to 10,000+ Channels
  • High Performance Conditioning with Integrated A/D
  • Digital I/O & DSP for Control applications
  • Gigabit Ethernet / USB / EtherCAT/Custom Interfaces
  • Supports High speed (Up to 200KS/s/ch) & low speed (Up to 1KS/s/ch) & DIO cards in the same chassis.
  • Onboard redundant data storage
  • Turnkey & API Software

Turnkey Systems Series 68xx

Feature

  • Laboratory or Portable or 19" rack mounting Applications - 4 Slot / 8 slot / 10 Slot enclosures
  • Integrated Signal Conditioning and Digitizer solution
  • 8-32 Channel Systems for Voltage, IEPE & Strain
  • 32-128 Channel Thermocouple Systems
  • Gigabit Ethernet / USB / EtherCAT / Custom Interfaces
  • Bundled Turnkey OEM DAS Software - PI660XP

Transient Recorders Series 5800

Feature

  • High BW Bridge/ICP/Voltage Signal Conditioning
  • High Speed A/D - up to 10MS/s/ch, 16 bit data or high resolution 24 bit data at 200KS/s/ch
  • Harsh Environment or Laboratory rated 3ch or 16 ch Enclosures with daisy chaining capability
  • 8MS onboard storage per ch, 40Hrs battery backup
  • Gigabit Ethernet Interface, Turnkey Software

Ruggedized Ethernet DAS Series 73xx / 74xx

Feature

  • Rugged, High Accuracy Signal Conditioning 16-channel DAS blocks
  • Strain, Bridge, IEPE, Voltage inputs
  • High Resolution 24-Bit A/D, Gigabit Ethernet Interface
  • Sampling rates of 24kS/s, 102.4kS/s or 204.8kS/s per ch
  • Real-Time Temperature Compensation of Gain, Zero & Excitation from -20°C to +50°C
  • IRIG A/B/G Time stamping, Turnkey & API Software

Enclosure Solutions: Series 6000 Signal Conditioning and DAS

Feature:
  • Any number or combination of racks up to 8092+ channels configurable as a single Signal Conditioning and Data Acquisition system
  • 50ns channel to channel time correlation
  • Over 6 MS/s, simultaneous sampling per system
  • Multiple, distributed system support
  • Per chassis On-board storage for data redundancy
  • Distributed Sample Clock, Alarm & Calibration Bus
  • IRIG A, B or G Time Synchronization
  • Supports any I/O module in any slot: Combination of High Speed, Low Speed and DIO
  • Gigabit Ethernet / USB / SCRAMNET /EtherCAT / Custom Interfaces / Gateways
  • Analog outputs for external digitizer systems

Typical Implementation Diagram: Series 6000 Signal Conditioning and Data Acquisition System

Typical Implementation Diagram: Series 6000 Data Acquisition and Control Application

Feature:
  • Data Acquisition System with Signal Conditioning and Digitizer cards and with DSP Control Data Processor Card
  • User defined PID algorithms
  • Simultaneous acquisition, recording and display of data from the measurement transducers while the DSP is executing the PID algorithm
  • Data from any channel, analog or digital, along with inputs and outputs of the Control Processor itself is available for use in the control or data processing algorithms within 2 sampling periods
  • Floating point digital signal processor with 16 or 32 MB program/data memory
  • ±10 Volt analog outputs (DAC) with smoothing filter
  • 15 or more Digital Outputs
  • 64 Displayable and Recordable control outputs with alarms
  • Analog & digital output expansion on daughter board for more control outputs if required.
  • Pre-programmed control algorithms are available.
  • JTAG and IEEE 1145.1 Buffered Serial Ports
  • Completely tailored application specific implementation as per user requirements.

Connector Panels:

Control Panels:

Portable Mobile SCDAS:

Integration and Rack Mounted Solutions

The classical approach to embedded system testing used different testing environments and different test specification techniques on module test, SW integration test, HW /SW integration test and system integration test level.

Test Boxes:

As part of the Integrated Solutions, portable / 19" rack mountable test boxes can be provided, customized to meet the stand alone system test and verification requirements. These can be provided with LED displays, load, test and measurement points.

These can be provided with a complete cable loom kit that can be easily interfaced to the test solution connectors along with an integral test software panel that can be accessed and used by the user for standalone testing and verification of the test solution before connecting to the Unit Under Test (UUT).

Analog Data Recorder for Redundant Data Recording with Series 6000 DAS:

Featurs :
  • 19" Rack mountable recorder for fail-safe redundant, synchronized Data Recording.
  • 4 channels to 128+ channels or higher configuration
  • Custom specific hardware and software compatible to the Series 6000 SCDAS System.
  • Recording of high sampling rate wideband analog outputs and low sampling rate filtered analog outputs from the primary Series 6000 system.
  • Integrated time synchronization through trigger pulse from 6000 System.
  • Application specific software maintains the test definition, flow and reports generation.
  • Portable solution can also be provided.

IO Modules Chart:

Controller Modules

Model 6094



Feature:
  • Built in storage
  • Ethernet, USB and PCM Output (optional)
  • Chassis Expansion possibility

Model 6096



Feature:
  • Controller Module
  • Ethernet, USB communication
  • Built in storage

Varied Signal Conditioning Modules

Signal Conditioning Transducer Amplifier Modules

Model 6060



Feature:
  • Isolated excitation & input with 300 Volts common mode
  • Plug-in channel configuration & calibration card
  • Voltage & current excitation with remote sensing
  • Automatic zero & balance
  • Voltage substitution, DAC or 2/4 step shunt calibration
  • Gains 1 to 5,000 with 50 kHz or 100 kHz bandwidth
  • Four six-pole low-pass filters, optional programmable filter
  • Up to 200 kS/s per channel with 16-bit resolution

Model 6040



Feature:
  • 16 Digital inputs and outputs
  • Compatible with TTL and CMOS (6040-1)
  • Optic isolated inputs (6040-2)
  • Form C relay outputs (6040-2)
  • Automatic alarm responses
  • Programmable glitch capture
  • Input / Output status display

Model 6030



Feature:
  • Dual inputs, strain/bridge or IEPE transducers
  • Programmable bridge configuration
  • Voltage & current excitation with remote sensing per channel
  • Automatic zero & balance
  • Voltage substitution and two or four step shunt calibration
  • Gains 1 to 5,000 up to 100 kHz bandwidth with 0.05% accuracy
  • Programmable low-pass filters
  • Up to 200kS/s per channel with 16-bit resolution
  • Dual buffered 10 Volt analog outputs

Model 6036



Feature:
  • Dual inputs, charge & IEPE
  • 0.04 to 10,000 mV/pC charge gain
  • 2-20mA current source for IEPE transducers
  • 1 to 5,000 voltage gain with ±0.05% accuracy
  • 100 kHz bandwidth
  • Charge & voltage insertion calibration
  • Continuously programmable, 4-pole low-pass filter
  • Up to 200kS/s per channel with 16-bit resolution
  • Buffered 10 Volt analog outputs
  • Two alarms with programmable upper & lower limits

Model 6052



Feature:
  • Programmable input configuration ¼, ½ & full bridge
  • Programmable excitation with remote sensing
  • Shunt & voltage calibration
  • Automatic zero & balance
  • Gains 1 to 5,000 with 0.05% accuracy
  • Up to 20kS/s per channel with 16-bit resolution
  • Buffered 10 Volt analog output
  • Two alarms with programmable upper & lower limits

Model 6029



Feature:
  • AC or DC coupled inputs
  • 2 to 20 mA current excitation
  • Gains 1 to 5,000 with 0.05% accuracy
  • 4, 6 or 8-pole, low-pass filter
  • 100 kHz signal bandwidth
  • Up to 200 kS/s per channel with 16-bit resolution
  • Buffered ±10 Volt analog output

Model 6042

6042



Feature:
  • Floating point digital signal processor with 16 or 32 MB program/data memory
  • ±10 Volt analog outputs (DAC) with smoothing filter
  • 64 Recordable outputs with alarms
  • Analog & digital output expansion on daughter board
  • Preprogrammed algorithms
  • JTAG and IEEE 1145.1 Buffered Serial Ports

Model 6068

6068



Feature:
  • Plug-in module configures channel for multiple transducer types & calibration modes
  • Voltage & current excitation with remote sensing
  • Isolated excitation & input with 300 Volts common mode
  • Voltage & shunt calibration
  • Gains 1 to 5,000 with 100kHz bandwidth
  • Up to 200kS/s per channel with 16-bit resolution
  • Continuously programmable 6-pole low pass filter

Model 6028

6028



Feature:
  • Differential input, ±10 Volts, ±50 Volts with optional attenuator
  • Buffered ±10 Volts analog outputs for redundancy
  • Four-pole filter, 100 Hz to 20 kHz
  • Up to 100 kS/s per channel with 16-bit digitizer
  • Two alarms with programmable upper and lower limits

Model 6017



Feature:
  • Voltage & thermocouple inputs
  • Optional thermocouple reference junction box
  • Gains 1 to 5,000 with 0.05% accuracy
  • Automatic zero & gain calibration
  • Low-pass filter
  • Up to 2 kS/s per channel with 16-bit resolution
  • Two alarms with programmable upper & lower limits

Model 6013

6013



Feature:
  • Voltage, thermocouple & DC-LVDT inputs
  • Optional thermocouple reference junction box
  • Gains 1 to 5,000 with 0.05% accuracy
  • Automatic zero & gain calibration
  • Four-pole, low-pass filter
  • Up to 10 kS/s per channel with 16-bit resolution
  • Two alarms with programmable upper & lower limits

Model 6018



Feature:
  • RTDs, potentiometers & other current excited transducers
  • Programmable current excitation
  • Gains 1 to 5,000 with 0.05% accuracy
  • Automatic zero & gain calibration
  • Four-pole, low-pass filter
  • Up to 10 kS/s per channel with 16-bit resolution
  • Two alarms with programmable upper & lower limits

Model 6032



Feature:
  • Quarter, half & full bridge conditioning
  • Programmable excitation with remote sensing
  • Shunt & voltage calibration
  • Automatic zero & balance
  • Gains 1 to 5,000 with 0.05% accuracy
  • Fixed or programmable filter
  • Up to 20 kS/s per channel with 16-bit resolution
  • Two alarms with programmable upper & lower limits

Model 6038



Feature:
  • Programmable input configuration, 1/4, 1/2 & full bridge
  • Programmable excitation with remote sensing
  • Shunt & voltage calibration
  • Automatic zero & balance
  • Gains 1 to 5,000 with 0.05% accuracy
  • Four-pole, low-pass filter
  • Up to 10 kS/s per channel with 16-bit resolution
  • Two alarms with programmable upper & lower limits

Model 6039



Feature:
  • Programmable input configuration, 1/4, 1/2 & full bridge
  • Programmable voltage excitation with remote sensing
  • Additional 12 or 15 Volt transducer power
  • Two-step shunt & voltage substitution calibration
  • Gains 1 to 5,000 with 0.05% accuracy
  • Programmable 4, 6 or 8 pole low-pass filter
  • Up to 10 kS/s per channel with 16-bit resolution

Model 6047



Feature:
  • IRIG A, B and G
  • 1 Microsecond resolution
  • 100 mV to 10 Volt peak-to-peak input
  • Days, hours, minutes, seconds, milliseconds and microseconds
  • Simultaneous BCD and binary outputs
  • Time kept by disciplined clock if IRIG signal is lost

Model 6014 8-Channel Accelerometer Amplifier-Filter-Digitizer



Feature:
  • Programmable input configuration, 1/4, 1/2 & full bridge
  • Programmable voltage excitation with remote sensing
  • Additional 12 or 15 Volt transducer power
  • Two-step shunt & voltage substitution calibration
  • Gains 1 to 5,000 with 0.05% accuracy
  • Programmable 4, 6 or 8 pole low-pass filter
  • Up to 10 kS/s per channel with 16-bit

Model 6031 2-Channel Transducer Amplifier-Filter-Digitizer



Feature:
  • Plug-in channel configuration & calibration card
  • Voltage & current excitation including remote sense
  • Gains 1 to 5,000 with 0.05% resolution
  • 50 kHz or 100 kHz bandwidth
  • Automatic zero & balance
  • Programmable low pass filters
  • Voltage substitution gain calibration
  • Digitized & analog outputs
  • Up to 250kS/s per channel with 16-bit resolution
  • Dual buffered 10 Volt analog outputs

Model 6033 8-Channel Strain/Bridge Transducer Amplifier-Filter-Digitizer



Feature:
  • Quarter, half & full bridge conditioning
  • Voltage excitation up to 12 Volts
  • Shunt & voltage calibration
  • Automatic zero & balance
  • Gains 1 to 5,000 with 0.05% accuracy
  • Four-pole low-pass filter
  • Up to 10 kS/s per channel with 16-bit resolution
  • Two alarms with programmable upper & lower limits

Model 6035 8-Channel Strain/Bridge Transducer Amplifier-Filter-Digitizer



Feature:
  • Programmable input configuration, 1/4, 1/2 & full bridge
  • Voltage excitation programmable / regulated for each channel
  • Shunt & voltage calibration
  • Automatic balance & zero
  • Gains 1 to 5,000 with 0.05% accuracy
  • Four-pole, low-pass filter
  • Up to 10 KS/s per channel with 16-bit resolution
  • Two alarms with programmable upper & lower limits

Model 6037 8-Channel Strain/Bridge Transducer Amplifier-Filter-Digitizer



Feature:
  • Programmable input configuration, 1/4, 1/2 & full bridge
  • Automatic gain ranging
  • Strain gage simulation resistor Excitation up to 12 Volts, regulated per channel
  • Automatic balance & zero
  • Voltage & bipolar shunt calibration
  • Four frequency programmable low-pass filter
  • Up to 10kS/s per channel with 16-bit resolution
  • Two alarms with programmable upper & lower limits

Model 6053 4-Channel Strain/Bridge Transducer Amplifier-Filter-Analog Outputs

--- Coming Soon ---



Feature:
  • Isolated excitation & input with 300 Volts common mode
  • Programmable input configuration ¼, ½ & full bridge
  • Programmable excitation with remote sensing
  • Shunt & voltage calibration
  • Automatic zero & balance
  • Gains 1 to 5,000 with 0.05% accuracy
  • Up to 40 kS/s per channel with 16-bit resolution
  • Two buffered 10 Volt analog outputs per channel
  • Two alarms with programmable upper & lower limits

Model 6065 2-Channel Instrumentation Amplifier-Filter-Digitizer, 300CMV



Feature:
  • Isolated input with 300 Volts common mode
  • Automatic zero
  • Voltage Substitution Calibration
  • Gains 1 to 5,000 with 50 kHz or 100 kHz bandwidth
  • Programmable low-pass filters
  • Up to 200kS/s per channel with 16-bit resolution
  • Dual buffered 10 Volt analog outputs

Model 6044 32-Bit Discrete Input/Output with Alarms



Feature:
  • 32 Discrete digital inputs/outputs
  • TTL/CMOS or isolated (28V) inputs
  • TTL or open collector outputs
  • Program Mode for direct programming of discrete outputs
  • Alarm Mode generates discrete outputs based on limits set for measurement channels
  • Programmable persistence prevents false alarms

Model 6060GV 2-Channel Transducer Amplifier-Filter-Digitizer, Galvanic 300CMV



Feature:
  • Galvanically isolated excitation & input with 300 Volts common mode
  • Plug-in channel configuration & calibration card
  • Voltage & current excitation with remote sensing
  • Automatic zero & balance
  • Voltage substitution, DAC or 2/4 step shunt calibration
  • Gains 1 to 5,000 with 50 kHz or 100 kHz bandwidth
  • Four six-pole low-pass filters, optional programmable filter
  • Up to 200 kS/s per channel with 16-bit resolution
  • Dual buffered 10 Volt analog outputs

Model 6062 2-Channel Transducer Amplifier-Filter-Digitizer, 10CMV



Feature:
  • Plug-in channel configuration & calibration card
  • Voltage & current excitation with remote sensing
  • Automatic zero & balance
  • Voltage substitution, DAC or 2/4 step shunt calibration
  • Gains 1 to 5,000 with 50 kHz or 100 kHz bandwidth
  • Four six-pole low-pass filters, optional programmable filter
  • Up to 200 kS/s per channel with 16-bit resolution
  • Dual buffered 10 Volt analog outputs

Model 6041 16-Bit Test Sequencer



Feature:
  • 16 Digital sequencer outputs
  • Up to 16 time programmable states for each output
  • ±0.01% Time accuracy
  • TTL/CMOS or relay logic
  • 1 Millisecond resolution

Model 6048 4-Channel 32-Bit Frequency/ Period/ Counter



Feature:
  • Four independent 32-bit channels
  • Digital or zero crossing triggers
  • Optic isolated inputs
  • Noise reduction input filters
  • Programmable time base
  • 12 Volt isolated power for inputs
  • Companion Calibration Relay Matrix

Model 6049 Quad 32-Bit Quadrature Decoder



Feature:
  • Four independent 32-bit channels
  • Optic isolated inputs
  • Noise reduction input filters
  • 12 Volt isolated power for inputs

Model 6129, 8-Channel AC/DC-Coupled/IEPE Amplifier-Filter-Analog Output



Feature:
  • AC or DC coupled inputs
  • 2 to 20 mA current excitation
  • Gains 1 to 5,000 with 0.05% accuracy
  • 4, 6 or 8-pole, low-pass filter
  • 100 kHz signal bandwidth
  • Buffered ±10 Volt analog output

Model 6160 2-Channel Transducer Amplifier-Filter-Analog Output, 300CMV



Feature:
  • Isolated excitation & input with 300 Volts common mode
  • Plug-in channel configuration & calibration card
  • Voltage & current excitation with remote sensing
  • Automatic zero & balance
  • Voltage substitution, DAC or 2/4 step shunt calibration Gains 1 to 5,000 with 50 kHz or 100 kHz bandwidth
  • Four six-pole low-pass filters, optional programmable filter
  • Dual buffered 10 Volt analog outputs

Model 6120, 2-Channel Strain/Bridge/IEPE Amplifier-Filter-Analog Output



Feature:
  • Dual inputs, strain/bridge or IEPE transducers
  • Programmable bridge configuration
  • Voltage & current excitation with remote sensing per channel
  • Automatic zero & balance
  • Voltage substitution and two or four step shunt calibration
  • Gains 1 to 5,000 up to 100 kHz bandwidth with 0.05% accuracy
  • Programmable low-pass filters
  • Dual buffered 10 Volt analog outputs

Model 6136, 4-Channel Charge/IEPE Amplifier-Filter-Analog Output



Feature:
  • Dual inputs, charge & IEPE
  • 0.04 to 10,000 mV/pC charge gain
  • 2-20mA current source for IEPE transducers
  • 1 to 5,000 voltage gain with ±0.05% accuracy
  • 100 kHz bandwidth
  • Charge & voltage insertion calibration
  • Continuously programmable, 4-pole low-pass filter
  • Buffered 10 Volt analog outputs

Model 6131, 2-Channel Transducer Amplifier-Filter-Analog Output



Feature:
  • Plug-in channel configuration & calibration card
  • Voltage & current excitation including remote sense
  • Gains 1 to 5,000 with 0.05% resolution
  • 50 kHz or 100 kHz bandwidth
  • Automatic zero & balance
  • Programmable low pass filters
  • Voltage substitution gain calibration
  • Dual buffered 10 Volt analog outputs

Model 6152, 4-Channel Strain/Bridge Transducer Amplifier-Filter-Analog Output



Feature:
  • Programmable input configuration 1/4, 1/2 & full bridge
  • Programmable excitation with remote sensing
  • Shunt & voltage calibration
  • Automatic zero & balance
  • Gains 1 to 5,000 with 0.05% accuracy
  • Buffered 10 Volt analog output

Model 6165, 2-Channel Instrumentation Amplifier-Filter-Analog Output, 300CMV



Feature:
  • Dual inputs, charge & IEPE
  • 0.04 to 10,000 mV/pC charge gain
  • 2-20mA current source for IEPE transducers
  • 1 to 5,000 voltage gain with ±0.05% accuracy
  • 100 kHz bandwidth
  • Charge & voltage insertion calibration
  • Continuously programmable, 4-pole low-pass filter
  • Buffered 10 Volt analog outputs

Model 6168, 2-Channel Transducer Amplifier-Filter-Analog Output, 300CMV



Feature:
  • Plug-in module configures channel for multiple transducer types & calibration modes
  • Voltage & current excitation with remote sensing
  • Isolated excitation & input with 300 Volts common mode
  • Voltage & shunt calibration
  • Gains 1 to 5,000 with 100 kHz bandwidth
  • Continuously programmable 6-pole low pass filter
  • Dual buffered 10 Volt analog outputs

Instrumentation Amplifier Modules

Model 6125



Feature:
  • Dual inputs, voltage and voltage mode charge
  • Automatic zero gain calibration
  • Gains 1 to 5,000 with 0.05% resolution
  • 50 or 100 kHz bandwidth
  • 100K or 200K sample rate, 16-bit resolution

Model 6165



Feature:
  • 16 Digital inputs and outputs
  • Compatible with TTL and CMOS (6040-1)
  • Optic isolated inputs (6040-2)
  • Form C relay outputs (6040-2)
  • Automatic alarm responses
  • Programmable glitch capture
  • Input / Output status display

Model 70A



Feature:
  • Gains from 0.01 to 5,000,
  • 0.1% or 0.02% gain accuracy
  • 100 kHz bandwidth
  • 300 Volt common mode
  • 2 or 6-pole selectable low-pass filter
  • Voltage substitution calibration
  • Dual, 100 mA, floating outputs
  • Optional AC input coupling

Signal Conditioning Categories

Automated Amplifiers

Series 6100



Feature:
  • High Performance Conditioning
  • Static & Dynamic Strain, RTD, Charge, IEPE, Instrumentation Amp
  • 300V Common Mode Rejection
  • Buffered Analog Outputs to External A/D
  • Turnkey & API Software

Model 6005



Feature:
  • DC Enclosure for 10 I/O Modules
  • USB 2.0 Interface provides 5+ MS/s aggregate data rate
  • Calibration voltage input
  • Alarm busses for control external equipment
  • Optional remote operation using gigabit Ethernet
  • Optional on-board data storage
  • Built-in fans and front mounted connections

Model 6008



Feature:
  • DC Enclosure for 4 I/O Modules
  • USB 2.0 Interface provides 5+ MS/s aggregate data rate
  • Calibration voltage input
  • Alarm busses for control external equipment
  • Optional remote operation using gigabit Ethernet
  • Optional on-board data storage

Model 9355



Feature:
  • Voltage & current excitation
  • Remote sensing & excitation interrupt
  • Two-range automatic balance
  • DAC shunt calibration
  • 4-step, bipolar resistive shunt calibration
  • Gains 1 to 10,000
  • Voltage substitution calibration
  • 300 Volt common mode
  • Eight low-pass filters, dual outputs

Model 6000U 16-Slot, USB Data & Control Interface Enclosures



Feature:
  • Enclosure for 16 I/O modules
  • USB 2.0 Interface provides 5+ MS/s aggregate data rate
  • Calibration voltage distribution
  • Alarm busses for control external equipment
  • Optional remote operation using gigabit Ethernet
  • Optional on-board data storage
  • Built-in fans and cable tray

Model 6010U 4-Slot, USB Data & Control Interface Enclosures



Feature:
  • Enclosure for 4 I/O modules
  • USB 2.0 Interface provides 5+ MS/s aggregate data rate
  • Calibration voltage distribution
  • Alarm busses for control of external equipment
  • Optional remote operation using gigabit Ethernet
  • Optional on-board data storage
  • Built-in fans and cable tray

Model 6005U 10-Slot, 12 VDC, USB Data & Control Interface Enclosures



Feature:
  • DC Enclosure for 10 I/O Modules
  • USB 2.0 Interface provides 5+ MS/s aggregate data rate
  • Calibration voltage input
  • Alarm busses for control external equipment
  • Optional remote operation using gigabit Ethernet
  • Optional on-board data storage
  • Built-in fans and front mounted connections

Model 6000E 16-Slot, Ethernet Data & Control Interface Enclosures



Feature:
  • Enclosure for 16 I/O modules
  • Ethernet Interface provides 5+ MS/s aggregate data rate
  • Calibration voltage distribution
  • Alarm busses for control of external equipment
  • Optional on-board data storage
  • Built-in fans and cable tray

Model 6005E 8-Slot, 12 VDC, Ethernet Data & Control Interface Enclosures



Feature:
  • DC Enclosure for 8 I/O Modules
  • Ethernet Interface provides 5+ MS/s aggregate data rate
  • Calibration voltage distribution
  • Alarm busses for control external equipment
  • Optional on-board data storage
  • Built-in fans and front mounted connections

Turnkey Systems

Model 6815 Turnkey Voltage/IEPE/Strain/Bridge/ LVDT Data Acquisition System



Feature:
  • 16 or 32 Ch Voltage/ICP/IEPE/ Strain/Bridge/LVDT Input
  • BNC & RJ45 Input Connectors
  • AC/DC Coupling for Voltage/IEPE
  • Bridge Completion, Shunt Cal & Balance for Strain/Bridge
  • IRIG Time A, B or G
  • PI660 Turnkey Software Included
  • Shipping Container

Model 6820 Turnkey Voltage/IEPE/ICP Data Acquisition System



Feature:
  • 8, 16, 24 or 32 Channels IEPE/Voltage Input
  • 200kS/s 16-Bit Digitizer Per Channel
  • BNC Inputs
  • AC/DC Coupling
  • IRIG Time A, B or G
  • PI660 Turnkey Software Included
  • Shipping Container

Model 6840 Turnkey Strain/Bridge/LVDT Data Acquisition System



Feature:
  • 8, 16, 24 or 32 Channels Strain/Bridge/LVDT Input
  • 10kS/s 16-Bit Digitizer
  • Bridge Completion, Remote Sense, Shunt Calibration Lowpass Filters
  • RJ45 Input Connector
  • IRIG Time A, B or G
  • PI660 Turnkey Software Included
  • Shipping Container

Model 6825 Turnkey ICP/IEPE Data Acquisition System



Feature:
  • 16 Channels ICP/IEPE/Voltage Input
  • 200kS/s 16-Bit Digitizer
  • High Level Buffered/Calibrated Analog Outputs
  • AC/DC Coupling
  • BNC Inputs
  • IRIG Time A, B or G
  • Digital I/O
  • PI660 Turnkey Software Included

Model 6830 Turnkey Instrumentation Amplifier System



Feature:
  • 16 Channels Voltage/Instrumentation
  • 200kS/s, 16-Bit Digitizer
  • High Level Buffered/Calibrated Analog Outputs
  • AC/DC Coupling, 3-Pin MIL Inputs
  • IRIG Time A, B or G, Digital I/O
  • PI660 Turnkey Software Included

Model 6845 Turnkey Strain/Bridge Data Acquisition System



Feature:
  • 16 or 32 Channels Strain/Bridge Input
  • 10kS/s, 16-Bit Digitizer
  • Bridge Completion, Remote Sense, Shunt Calibration, Low-pass Filters
  • RJ45 Input Connector
  • IRIG Time A, B or G
  • Digital I/O
  • PI660 Turnkey Software Included

Model 6860 3U Thermocouple Scanner



Feature:
  • 32, 64 or 96 Channel Configurations in a 3U Rack Mount Enclosure
  • Utilizes External Uniform Temperature References (UTRs)
  • UTR Model 6084-32, Screw Terminal Reference Allows for Integration of Any TC type and/or
  • UTR Model 6084-32-RM is a 2U, Rack Mountable UTR with Front Mounted 2-pin Mini TC Jacks (T, K, E or J)
  • IRIG Time - A, B or G
  • PI660 Turnkey Software Included

Conditioning & Transient Recording System

Series 7200 Ruggedized 16-Channel Strain/Bridge/Voltage Data Acquisition



Feature:
  • 16-Channels strain gage, bridge or voltage transducers
  • Ethernet control and data interface
  • Real time temperature correction of Gain, Zero & Excitation from -20°C to +50°C
  • 0.05% or better accuracy over full gain & temperature range
  • 10 kHz analog bandwidth, gain 1 to 1,000
  • 24-Bit A/D programmable up to 24k S/s per channel, Wide range programmable filter, 80 dB/octave
  • IRIG A, B & G time decoding and recording
  • 1 μS synchronized sampling of multiple enclosures
  • Ruggedized for tough environments
  • 20 to 30 Volt DC power

Series 7300 High Speed Ruggedized 16-Channel Strain/Bridge/Voltage Data Acquisition



Feature:
  • 16-Channels strain gage, bridge or voltage transducers
  • Ethernet control and data interface
  • Real time temperature correction of Gain, Zero & Excitation from -20°C to +50°C
  • 0.1% or better accuracy over full gain & temperature range
  • 50 kHz analog bandwidth, gain 1 to 1,000
  • 24-Bit A/D programmable up to 102.4k S/s per channel ,Wide range programmable filter, 80 dB/octave
  • IRIG A, B & G time decoding and recording
  • 1 μS synchronized sampling of multiple enclosures
  • 20 to 30 Volt DC power

Series 7324 High Speed Ruggedized 16-Channel Strain Bridge IEPE Ethernet DAS



Feature:
  • 16-Channels strain gage, bridge, Voltage Transducers, Dynamic Strain or IEPE
  • Ethernet control and data interface
  • Real time temperature compensated (Gain & Excitation) from -20°C to +50°C
  • 0.05% or better accuracy over full gain & temperature range
  • 45 kHz analog bandwidth, gain 1 to 1,000
  • 24-Bit A/D programmable up to 100kS/s per channel
  • FIR filter, 128 tap
  • IRIG A, B & G time decoding and recording
  • 1 μS synchronized sampling of multiple enclosures
  • Ruggedized for tough environments
  • 20 to 30 Volt DC power

Series 7400 High Speed Ruggedized 16-Channel Strain Bridge Voltage Ethernet DAS



Feature:
  • 16-Channels strain gage, bridge or voltage transducers
  • Ethernet control and data interface
  • Real time temperature compensated (Gain & Excitation) from -20°C to +50°C
  • 0.1% or better accuracy over full gain & temperature range
  • 90 kHz analog bandwidth, gain 1 to 1,000
  • Wide range programmable filter, 80 dN/octave
  • 24-Bit A/D programmable up to 200kb/s per channel
  • IRIG A, B & G time decoding and recording
  • 1 μS synchronized sampling of multiple enclosures
  • Ruggedized for tough environments
  • 20 to 30 Volt DC power

7424 High Speed Ruggedized 16-Channel Strain Bridge Voltage IEPE Ethernet DAS



Feature:
  • 16-Channels strain gage, bridge, Volatage Transducers, Dyanamic Strain or IEPE
  • Ethernet control and data interface
  • Real time temperature Compensated from -20°C to +50°C
  • 0.05% or better accuracy over full gain & temperature range
  • 90 kHz analog bandwidth, gain 1 to 1,000
  • 24-Bit A/D programmable up to 200kS/s per channel
  • FIR filter, 128 tap
  • IRIG A, B & G time decoding and recording
  • 1 μS synchronized sampling of multiple enclosures
  • Ruggedized for tough environments
  • 20 to 30 Volt DC power

Ruggedized Ethernet Data Acquisition Systems

Model 5800
Feature:
  • Record fast events, up to 10 MS/s
  • One pre-trigger and two post-trigger sample rates
  • Rugged 3 or 16 channel, battery operated enclosures
  • 16 Channel A/C powered laboratory enclosures
  • Ethernet interface with Windows software
  • Dual inputs, bridge and ICP
  • Programmable for 1/4, 1/2 and full bridges
  • Voltage & shunt calibration
  • Automatic, hands-off operation

Signal Conditioning & Recording Software’s

PI660 Professional Test & Measurement Software



Feature:

PI660 is the choice of most Series 6000 users for test management, data acquisition, and data display. It is a turnkey application that runs on Microsoft Windows Operating Systems. PI660 provides all the tools for test definition, setup & tracking, transducer calibration, data acquisition, display, distribution, plotting, replay, export, and quality validation

PI610 Signal Conditioning Software



Feature:

PI610 is fully configured and ready to use. It provides on screen programming of operating parameters or can download parameters from an Access compatible database file. It includes a window that graphically displays amplifier excitation and output.

Additionally, users can integrate programming functions inside existing application software using an SDK or high-level instruction set.

PI580 Transient Recording System Software



Feature:

PI580 is the turnkey application software for the Series 5800 Transient Recording System. PI580 operates in the Windows environment and includes everything for system setup, calibration, data display, debrief and export for post processing.

MODEL ACS2000 Calibration System

Description

Pacific Instruments Model ACS2000, Automated Calibration System will align, calibrate and certify programmable transducer signal conditioners and instrumentation amplifiers to factory or user performance specifications. Product specific cable sets and software enable a single calibration system to be used with any supported Pacific Instrument's products.

The ACS2000 is a fully automated test station with the flexibility to run a single performance test or complete calibration and certification procedures. It provides uniform performance testing regardless of operator ability level. Automated calibration and certification increases productivity by reducing the time to calibrate a unit by as much as 80%, providing a quick payback of the initial investment. It also eliminates human errors that may occur when setting up instrument parameters and measuring and recording test results.

Feature:
  • Automated NIST traceable calibration of amplifiers and signal conditioning
  • Performance measurement and certification
  • Archived and printed test reports
  • Increased measurement accuracy by periodic recalibration
  • Minimize human errors
  • Cable sets and software available for Series 5800, 6000, 6100, 7000 and 9000 Pacific product lines

System Description

Calibration and certification are performed on individual channels installed in the enclosure. The system provides automatic configuration of the input and output test circuits as well as set-up of test equipment and test articles to accomplish each measurement or calibration. All test equipment is certified to NIST traceable standards and is easily removed from the system for perodic recertification. The ACS2000 uses a specially designed and shielded test fixture with three levels of computer isolation to achieve low noise, high accuracy measurements. Low-noise, low-thermal EMF relays are used exclusively for input switching. Calibration and certification software uses Standard Test Proceedures that are specific to each model and call universal parameter test and calibration routines. The provided test procedures are in ASCII, text-based files that may be easily customized by the user without programming experience.

Sensor Simulation System

1.Resistive Sensor Simulation

Features:
  • Highly integrated board
  • Simulation of a wide variety of resistive sensors (PT100, PT1000, NTC, or PTC)
  • Original Equipment (OE) and Simulation test mode
  • Fully integrated in Alphi‘s Avionics Development System (AT)
  • Controlled via Ethernet
  • High accuracy time synchronization
  • 2-, 3-, or 4-wire operation
  • API to user-written applications
Application Scope

The module provides an Ethernet controlled simulation for resistive sensors, such as PT100, PT1000, NTC, or PTC. The resistor value is accessible and directly controlled via protocol / AT / API. Additional settings enable the use of different scales, such as temperature or pressure scales. The transformation of the input scale to the actual resistor value is performed by the AT driver and the controller of the system.

Functional Description

Each physical channel of the -RSS8 is fully isolated from the other channels, and it is located on a piggy-back specifically matched to the required application. Up to eight channels (RSM) can be mounted on a single -RSS8 board. The -RSS8 commandinterface is standard UDP via LAN.

The following resistive simulator modules (RSM) are currently available:

  • PT100 (RSM-PT100);
  • PT1000 (RSM-PT1000);
  • NTC (RSM-NTC);
  • PTC (RSM-PTC). PT500 and other types are available on request.

All modules can be operated within a ±10 V and ±10 mA range. For each sensor a specific resistor matrix is used to match the required resistor parameters.

2. Proximity Sensor Simulation

Key Features
  • The Sensor Simulation is integrated in a 6 U signal conditioning crate (PSSU)
  • 60 channel near/far simulation of proximity sensor signals
  • Near/far switching of the sensor is supported by relay
  • Open/Short signal manipulation (short-circuit current < 2 A) of the signal path is provided via relay circuitry
  • The relays are provided with a freewheeling diode
  • The needed coils should be supplied by the customer. Otherwise the coil’s parameters have to be specified by the customer in order to identify best possible comparison standard types.
  • The relays are controlled by an adequate discrete output module.
Circuit Diagram

The diagram shows an example of the near/far switching and the open/short failure simulation. The coils’ parameters have to be defined.

Application Notes

Engine Test Stands



Feature:
  • Rocket Motor & Components
  • Launch Vehicle
  • Quality Assurance
  • Acoustics

Wind Tunnel



Feature:
  • Turbine Engine Test Stand
  • Occupant Restraint Systems
  • Ejection seats
  • Emergency Shutdown

Explosive Tests



Feature:
  • Artillery & Bomb Range
  • Explosive Effects, Threat Reduction
  • Weapons & Military Vehicles
  • Heat Transfer & Analysis

Structures and Vibrations



Feature:
  • Aircraft Structure & Fatigue
  • Stress Analysis
  • Shock & Vibration
  • Aircraft Systems
  • Earthquake Engineering
  • Automotive Safety
  • Quality Assurance
  • Over-the-Road Vehicles

Transient Tests



Feature:
  • Crash Test
  • Automotive Safety
  • Railway Car, Track & Locomotive Performance
  • Shipping & Packing Materials

Rocket Motor Test Firing DAS



Feature:
  • Comprehensive Integrated proven Solution
  • Customized firing Control Panel
  • Real-Time Analysis of firing parameters for validation of materials
  • Transducer Calibration Facility
  • Offline Analysis

Subsonic Wind Tunnel Testing for Full-Scale Complex



Feature:
  • 300 Volt common mode
  • Fully floating input and excitation power
  • 4-Step shunt calibration with removable resistor module
  • High Accuracy with gains 1 to 5,00 and 100 kHz bandwidth
  • Six-pole anti-aliasing filter
  • "Front panel" signal monitor

Structural Earthquake Testing for Real Time Multi-Directional (RTMD) Facility DAS



Feature:
  • Wide range of input modules accommodating a wide range of transducers
  • Independent, channel-programmable sample rates
  • Times correlation (Synchronization) of channel sampled at different rates
  • On-board high-capacity data storage for primary or back-up data recording
Note: 60xx – card with ADC 61xx – card without ADC
