Ground Checkout Systems and Decom

We are pleased to provide the brief information on the comprehensive solutions for Ground Checkout Systems for telemetry provided through our exclusive Technology Alliance Partnership (TAP) with M/s JDA Systems, Germany. As the TAP and authorized System Integrators, Offshore Developers and Custom Engineering Centre for JDA, Symmetric can provide comprehensive, tailored and customized End to End telemetry Ground Checkout solutions which can be man portable, standard 19" rack mountable or Vehicle mounted. These systems use next generation digital core implementation architecture and are field proven across Europe and America in next generation mission critical military applications. We welcome your attention and look forward to talk to you on your specific requirements.

Antenna

VT – 004 40cm Auto Tracking Antenna

Features

  • Planer array simultaneous RHCP and LHCP antenna
  • L and S Band Reception (Optional C Band)
  • Single Channel Mono pulse
  • Autonomous auto tracking
  • Multiple mode slave tracking
  • Easy maintenance modular design
  • DC Brushless overrated motors
  • Absolute encoders in all rotating parts with better than 0.05º accuracy
  • On bore site video camera
  • Bus based internal communication
  • Ethernet remote control
  • Fully integrated auto – calibration system
  • Simultaneous receive and transmit option
  • Good performance in adverse weather conditions
  • Light weight composite and corrosion resistant construction throughout
  • Greatly reduced cabling
  • Less weight and better portability
  • Windows XP, 7, 8, 10 Based ACU Software

VT-012TM 1.2m Auto Tracking Antenna

Features

  • Simultaneous RHCP/LHCP or Vertical/ Horizontal parabolic reflector antenna
  • L, S & C Band Reception
  • Digital Rotary Scan Head
  • Autonomous auto tracking
  • Multiple mode slave tracking
  • Easy maintenance modular design
  • DC Brushless overrated motors
  • Absolute encoders in all rotating parts with better than 0.002° accuracy
  • Optional on bore site video camera
  • Bus based internal communication
  • Ethernet remote control and monitoring
  • No special ACU hardware needed
  • Fully integrated auto-calibration system
  • Simultaneous receive and optional transmit
  • Optional acquisition aid antenna
  • Light weight carbon fiber, composite and corrosion resistant construction throughout
  • Greatly reduced cabling
  • Less weight and better portability
  • Windows XP, 7, 8, 10 Based ACU Software

VT-020 2.0m Auto Tracking Antenna

Features

  • Simultaneous RHCP/LHCP or Vertical/ Horizontal parabolic reflector antenna
  • L, S & C Band Reception
  • Digital Rotary Scan Head
  • Autonomous auto tracking
  • Multiple mode slave tracking
  • Easy maintenance modular design
  • DC Brushless overrated motors
  • Absolute encoders in all rotating parts with better than 0.002° accuracy
  • Optional on bore site video camera
  • Bus based internal communication
  • Ethernet remote control and monitoring
  • No special ACU hardware needed
  • Fully integrated auto-calibration system
  • Simultaneous receive and optional transmit
  • Optional acquisition aid antenna
  • Light weight carbon fiber, composite and corrosion resistant construction throughout
  • Greatly reduced cabling

VT-002 Series Slave Tracking Anteenna

Features

  • Light weight composite and corrosion resistant construction throughout.
  • Fully integrated auto calibration system allows the antenna to be powered and operating at optimal capacity in minutes.
  • The fully integrated design makes the VT-002 fully man portable.
  • Easy maintenance modular design throughout requiresless access panels and offers higherreliability. Optional complete module spares kit available.
  • The VT-002 antenna is built around a bus centric design.
  • Main tracking controller running on an integrated embedded processor. Ethernet network control link to the antenna greatly reduces the required cabling and eases the installation, also allows for easy remote operation.
  • DC Brushless overrated motors with serial bus based controllers offering exceptional agility and reliability.
  • Absolute encoders in all rotating parts with better than 0.05° accuracy.
  • Planer array antenna offering improved signal gain, less weightand betterportability.
  • Hermetically sealed receiving head for better performance in adverseconditions.

VT- 004Q Auto Tracking Antenna

Features

  • Planer array simultaneous RHCP and LHCP antenna
  • L and S Band Reception, with C band option
  • Monopulse Auto tracking Technique
  • Autonomous auto tracking
  • Multiple mode slave tracking
  • Easy maintenance modular design
  • DC Brushless overrated motors
  • Absolute encoders in all rotating parts with better than 0.05° accuracy
  • Boresite HD video with optical zoom
  • Integrated tracking receivers, IMU and GPS
  • Ethernet remote control and monitoring
  • Fully integrated auto-calibration system
  • Good performance in adverse weather conditions without the need for a radome
  • Light weight composite and corrosion resistant construction throughout
  • Less weight ~14kg allows better portability as it requires no transport case or radome
  • Greatly reduced cabling
  • Human Language Based Remote Interface
  • Windows 7 thru 10 Based ACU Software

VT-005 Series Antenna Positioner

Features

  • It can rotate endlessly in the Azimuth axis and support a balanced antenna load of over five KG
  • It can support antenna systems with an output power of up to 1KW
  • The antenna positioner case contains all the electronics and mechanics required to drive the antenna positioned
  • A single door on the front of the case give easy and full access to the unit’s interior is required
  • On the bottom of the case you will find a single power input and a single Ethernet socket, these are use to power and control the antenna
  • The antenna powers up as soon as mains power between 96VAC and 264VAC is applied
  • The Ethernet interface switches automatically between 10 and 100 MBits/Sec to match the Ethernet system to which it is attached
  • The antenna power may be removed whenever the antenna is no longer rotating without damage to the unit
  • A level indicator is provided on the top of the VT-005 case and the unit should be levelled to within 3 degrees to level before operation

VT-006 60 cm Auto Tracking Antenna

Features

  • Parabolic reflector with radome
  • Simultaneous Vertical and Horizontal or RHCP and LHCP polarization
  • L, S & C Band Reception
  • Dual amplified RF outputs
  • Cavity filters to reject out of band signals, even in extreme interference conditions
  • Integrated dual channel tracking receiver
  • Bit Sync Data and Clock Outputs for standalone operation
  • Unlimited Azimuth movement with slip rings and RF rotary joints
  • DC Brushless overrated motors
  • Autonomous auto tracking
  • Multiple mode slave tracking
  • Easy maintenance modular design
  • Bus based internal communication
  • Simple single Cannon connector wiring
  • Ethernet remote control
  • Fully integrated auto-calibration system
  • Simultaneous receive and optional transmit
  • Good performance in adverse weather conditions
  • Light weight carbon fiber, composite and corrosion resistant construction throughout
  • Greatly reduced cabling, Less weight and better portability
  • Windows 7, 8, 10 based ACU Software

VT-007 60 cm Auto Tracking Antenna

Features

  • Parabolic reflector with radome
  • Simultaneous Vertical and Horizontal or RHCP and LHCP polarization
  • L, S & C Band Reception
  • Dual amplified RF outputs
  • Cavity filters to reject out of band signals, even in extreme interference conditions
  • Integrated dual channel tracking receiver
  • Bit Sync Data and Clock Outputs for standalone operation
  • Unlimited Azimuth movement with slip rings and RF rotary joints
  • DC Brushless overrated motors, Bus based internal communication
  • Autonomous auto tracking
  • Multiple mode slave tracking
  • Fully integrated auto-calibration system
  • Simultaneous receive and transmit option
  • May be installed on the nose of an aircraft
  • light weight composite and corrosion resistant construction throughout
  • Greatly reduced cabling, Less weight and better portability
  • Windows 7, 8, 10 based ACU Software

VT-008 60 cm Auto Tracking Antenna

Features

  • Simultaneous RHCP and LHCP reception
  • L and S Band Reception (optional C Band)
  • Single Channel Monopulse
  • DC Brushless overrated motors
  • Autonomous auto tracking, Multiple mode slave tracking
  • Easy maintenance modular design
  • Absolute encoders in all rotating parts with better than 0.05° accuracy
  • Bus based internal communication
  • Ethernet remote control
  • Fully integrated auto-calibration system
  • Simultaneous receive and optional transmit
  • Good performance in adverse weather conditions
  • Light weight composite and corrosion re-sistant construction throughout
  • Greatly reduced cabling
  • Less weight and better portability
  • Windows XP, 7, 8,10 Based ACU Software

VT-009 90 cm Auto Tracking Antenna

Features

  • Parabolic reflector with radome
  • Simultaneous Vertical and Horizontal or RHCP and LHCP polarization
  • L, S & C Band Reception
  • Dual amplified RF outputs
  • Cavity filters to reject out of band signals, even in extreme interference conditions
  • Integrated dual channel tracking receiver
  • Bit Sync Data and Clock Outputs for standalone operation
  • Unlimited Azimuth movement with slip rings and RF rotary joints
  • DC Brushless overrated motors
  • Autonomous auto tracking
  • Multiple mode slave tracking
  • Easy maintenance modular design
  • Bus based internal communication
  • Simple single Cannon connector wiring
  • Ethernet remote control
  • Fully integrated auto-calibration system
  • Simultaneous receive and optional transmit
  • Good performance in adverse weather conditions
  • Light weight carbon fiber, composite and corrosion resistant construction throughout
  • Greatly reduced cabling, Less weight and better portability
  • Windows 7, 8, 10 based ACU Software

VT-030 3.0m Auto Tracking Antenna

Features

  • Simultaneous RHCP/LHCP or Vertical/Horizontal parabolic reflector antenna
  • L, S & C Band Reception
  • Digital Rotary Scan Head
  • DC Brushless overrated motors
  • Autonomous auto tracking, Multiple mode slave tracking
  • Easy maintenance modular design
  • Absolute encoders in all rotating parts with better than 0.002° accuracy
  • On bore site video camera
  • Continuous azimuth movement
  • No special ACU hardware needed
  • Bus based internal communication
  • Ethernet remote control
  • Fully integrated auto-calibration system
  • Low noise, high gain first stage amplifier
  • Fully integrated auto-calibration system
  • Light weight composite and corrosion re-sistant construction throughout
  • Greatly reduced cabling
  • Less weight and better portability
  • Windows 7, 8,10 Based ACU Software

VT-063 6.3m Deep Space Tracking Antenna

Features

  • Light weight corrosion resistant materials and alloy construction throughout
  • Solid surface main antenna reflector technology manufactured from a carbon fibre and Kevlar honeycomb sandwich improved signal gain, less weight and better aerodynamics
  • Optional Monopulse high gain signal recovery head with built in tracking receivers. Fully integrated auto calibration system allows the antenna to be powered and operating at optimal capacity in minutes
  • Brushless overrated motors with bus based controllers offering exceptional agility
  • Absolute encoders in all rotating parts with better than 0.0001° accuracy
  • Optional slip ring units with dual RF rotary joints in azimuth offering continuous unlimited azimuth movement
  • Optional embedded high resolution camera system fitted on the centre line of the antenna with 36x Optical and 200x Digital zoom
  • Easy maintenance modular design throughout requires less access panels and offers higher reliability. Optional complete module spares kit available
  • The VT-063 antenna is built around an Ethernet network centric design. Although it will operate as a traditional reception or tracking antenna system if required it can optionally have available
  • Main tracking controller running Windows XP, Vista & 7. Network control link to the antenna greatly reduces the required cabling and thus the installation costs, also allows for easy remote operation
  • The antenna can be broken down for transport with standard trucks
  • Inherently stable physical design including optional GPS position and optional stabilized fluxgate platform making the system highly suitable for remote location, mobile or shipboard operation

Receiver

VT-RC-74

Features

  • One to Four Receivers Per 1U System
  • Post Detection Combiner Per Channel
  • Optional Digital Receiver Bit Sync
  • Ethernet Control Interface
  • Easy to use Graphic Interface
  • Remote Controllable
  • Multiple Band Operation:
    • 1435.5 - 1540.5 MHz
    • 1700.0 - 1850.0 MHz
    • 2185.0 - 2480.0 MHz
  • User Selectable Pre-Detect Filters
  • Programmable Pre-Detect Gain
  • User Selectable Post-Detect Filters
  • Programmable Post-Detect Gain
  • NTSC & PAL Video De-emphasis
  • AM and AGC Outputs for Auto Tracking Antennas
  • Low Total Noise of Less Than 6dB
  • High Absolute Sensitivity < -120 dbm
  • Wide Band Operation up to 30 MHz

VT-RF-70

Features

  • It is designed to be used for the reception of telemetry or video RF transmissions. Up to 4 Terabyte of storage in modular increments.
  • It is also unique as it is available with a standard USB interface, from which is draws both control and power, or on computers where this is not possible (some laptops which do not provide a high power capability) the 5V may be supplied separately via the on board 9 pin connector.
  • The receiver offers the option to be used locally, like a traditional receiver, or remotely even over very long links which can improve the total system flexibility and performance

Digital Receiver

Features

  • Multi Band Receiver
  • Complete Receiver (RF to Time Tagged De commutated Data)
  • USB 2.0 Interface
  • Rapid Synchronization
  • Integrated Time
  • Telemetry Encoder
  • Speech Audio Status
  • Speech Indicator Lines
  • Multiple preset memory storage
  • Trellis demodulation in all ARTM Modes

VT-RX-SC2U All Band Receiver

Features

  • Two Fully Digital Direct Conversion Receivers Per Chassis
  • RF SMA female inputs @ 50Ohm, VSWR < 1.5
  • Post Detection Combiner
  • Receives AM, FM, PM, BPSK, QPSK, SOQPSK
  • PM demodulation loss 1.5dB(max) @ 1Mbps/1rad
  • 0.4 to 1.5 rad @ PM 1Mbps BIØ-L
  • BPSK/QPSK output unique digital root nyquist (square) relating to output bandwidth
  • All Band Operation of 70MHz to 6GHz with 1KHz tuning resolution
  • Mini BNC analog outputs 0-5V AGC1, AM1, FM1(Video), AGC2, AM2, FM2(Video)
  • TTL level Data1, Clock1, Lock1, Data2, Clock2, Lock2
  • Time Reference through IRIG-B Time Decoder
  • Time Reference through GPS Receiver
  • RJ45 100MB Ethernet Remote Control & Monitoring Interface
  • TCP/IP Direct Receiver Interface
  • Dual RS232 pass through ports
  • AGC Signal Level and Time Broad-cast at 20Hz
  • Embedded 9-axis INU with 10Hz to 100Hz Broadcast

VT-RX-SC4U All Band Receiver

Features

  • Four Fully Digital Direct Conversion Receivers Per Chassis
  • All Band Operation of 70MHz to 6GHz with1KHz tuning resolution
  • Compact and low power design
  • Rugged construction
  • Best in class performance
  • 0.4 to 1.5 rad @ PM 1Mbps BIØ-L
  • RF SMA female inputs @ 50Ohm, VSWR <1.5
  • Pre detect Combiner & Post Detection Best Source Selector
  • Receives AM, FM, PM, BPSK, QPSK, AQPSK, AUQPSK,, OQPSK, SOQPSK,VIDEO
  • PM demodulation loss 1.5dB(max) @1Mbps/1rad
  • Mini BNC analog outputs 0-5V AGC1, AM1, FM1(Video), AGC2, AM2, FM2(Video)
  • TTL level Data1, Clock1, Lock1, Data2, Clock2, CLock2
  • RJ45 100MB Ethernet Remote Control & Monitoring Interface
  • TCP/IP Direct Receiver Interface
  • Dual RS232 pass through ports
  • Quad Channel Equalizer
  • AGC Signal Level and Time Broad-cast at 20Hz
  • Embedded 9-axis INU with 10Hz to 100Hz Broadcast
  • 6V-12V DC Operation, Weight 815g
  • Less Than 14W Heat Dissipation

VT-RC-74DE

Features

  • Two Fully Digital Direct Conversion Receivers Per Chassis
  • All Band Operation of 70MHz to 6GHz with 1KHz tuning resolution
  • Compact and low power design
  • Rugged construction
  • Best in class performance
  • Post Detection Combiner
  • Receives AM, FM, PM, BPSK, QPSK, SOQPSK
  • PM demodulation loss 1.5dB(max) @1Mbps / 1rad
  • 0.4 to 1.5rad @ PM 1 Mbps BIØ-L
  • BPSL/QPSK output unique digital root nyquist (square) relating to output bandwidth
  • Fully Programmable input BW and Input Filter with 1 Hz resolution
  • Programmable tracking BW to +/- 200 kHz resolution
  • Low Total Noise of Less Than 4dB
  • High Absolute Sensitivity < -125 dBm

VT-TS-70S Portable Transmitter

Features

  • Multiple Band Operation:
    • 1435.5 - 1540.5 &1700.0 - 1850.0 MHz
    • OR 2185.0 - 2480.0 MHz
    • OR Optional C Band
  • Wide bandwidth > 30Mbits/Sec
  • Programmable output power -30 to+10dbm
  • Internal modulation source
  • External modulation source 4.3 inch Colour Touch Screen
  • Easy to use Graphic Interface
  • Up to 8 hours of operation on one battery charge
  • External power input 12V
  • ENet/USB Remote Controllable
  • GPS position and time source
  • IRIG B Decoder / Generator
  • 1PPS External Output
  • Weight including batteries 1200gm

Telemetry Decoding

Portable Test Unit

Features

  • Dual Integrated 3db wide band antennas
  • Dual Multiple Band L, Upper L, S and
  • NATO band FM single receiver
  • External Antenna Inputs
  • Dual High performance Bit Synchronizers
  • Dual channel soft Decom
  • IRIG A, B and G Decoder with time seed and free – wheel feature
  • Integrated GPS sixteen channel receiver
  • Advanced decoder, Archival, display and analysis software
  • Full IRIG 106 chapter 10 support
  • 8.5 inch TFT touch screen display
  • Rugged fold down keyboard
  • 70MHz IF Output and INPUT
  • Integrated BNC Break Out Panel
  • Bit Sync Data Output suitable for external decryption
  • Single removable 1TB hard disk
  • IRIG 106 chapter 10 Recorder / Regenerator
  • Serial .DOT user equipment interfaces
  • Windows XP Based Software

Portable Test Unit 2

Features

  • Dual External Antenna Inputs
  • Dual multiple receivers
  • Dual Bit Synchronizers
  • Dual PCM de-commentators
  • Auto tracking antenna ACU Function
  • IRIG A, B and G Decoder/Generator with time seed and free-wheel feature
  • GPS sixteen channel receiver
  • Advanced PCM decoder, archival, display and analysis software
  • Battery powered up to 8 hours operation
  • 11.6 inch Full HD touch screen display
  • Rugged light weight chassis
  • Independent 70MHz IF Outputs
  • Integrated break out panel
  • Bit sync data and clock output suitable for external pre processing
  • Removable tablet controller SSD
  • IRIG106 Chapter 10 Recorder/Regenerator
  • Fully remote controllable
  • Serial .DOT user equipment interfaces
  • Windows 8 Based Software

BOB2 2 Channel Telemetry Station

Features

  • Supports the IRIG Standard Including Chapters 4, 8, 9 & 10
  • Full Telemetry Ground Station Functionality From Receiver O/P to Post Processing
  • Quad Independent Bit Sync & Decom Channels For Channels For High Speed Operation
  • Real Time and Playback Data Regeneration and Network Broadcast Capability
  • Low Power Operation with Low Heat Generation For Operation In Tight Spaces
  • Small Form Factor and Light Weight
  • Fitted with a Professional Grade Intel i5 Processor
  • Customizable To Support Customer Unique Applications

BOB2 4 Channel Telemetry Station

Features

  • Supports the IRIG Standards Including Chapters 4, 8, 9 & 10
  • Full Telemetry Ground Station Functionality From Receiver O/P to Post Processing
  • Quad Independent Bit Sync & Decom Channels For High Speed Operation
  • Real Time and Playback Data Regeneration and Network Broadcast Capability
  • Low Power operation with Low Heat Generation For Operation In Tight Spaces
  • Small Form Factor and Light Weight
  • Fitted with a Professional Grade Intel i5 Processor
  • Customizable To Support Customer Unique Applications

PCM Bit sync – Decom Simulator

USB-SD2 Decommutation

Features

  • Interface Type: USB, no jumpers or switches on the card
  • Transfer Notification: USB Driver on FIFO flip flop
  • Bus Speed: USB 2.0
  • Input Types: 2 Serial RS422 or TTL
  • Input Bit Rate: 100 bps to 32 Mbps
  • Input Code Type: NRZ-L BNC & Internal
  • Output Types: 2 Serial RS422 or TTL
  • Output Code Types: NRZ-L/M/S, BIO-L/M/,DM-M/S,RNRZ/RNRZR-9/11/15/17/23
  • Output Bit Rate: 100 bps to 32 Mbps
  • Maximum I/O Rate: 32 Mbps/Channel(Maximum 64 Mbps/Unit)
  • Time Sources: IRIG A, B and G
  • Bit Sync: Optional plug on daughter board with up to 2 bit syncs

TDS-1000

Features

  • Up to 8 telemetry streams of same or different format
  • Software de-commutation accommodates multiple data formats
  • Up to 20 Mbps single stream or 80 Mbps aggregate throughput
  • Complete Telemetry ground – station using optional bit sync and receiver
  • Built-in simulator for each stream with optional frame extension and multi-stream combining
  • Derived parameters using built-in math engine
  • Real-time and played-back data display of measurement and derived parameters on server and Client workstations
  • Real-time, encrypted data distributed to client workstations
  • Format and parameters setup by database imports (TMATS, Access, Excel, CSV, dBase)

PCI-SD4 BS

Features

  • Card Type Daughter card PCI PNP, no jumpers or switches on the card
  • Transfer Type DMA
  • Input Connector SMA and BNC, Auto-gaining input 20mV > 10 Vpp
  • Output Level TTL 75 Ohm and RS422 Switchable, BNC External and Internal
  • Data Polarity Normal or Inverted
  • Input Rate 100 bps to 15Mbps (or 32 Mbps)
  • Input Code Types NRZ-L/M/S, BIO-L/M/S, DM-M/S, RNRZ/RNRZR-9/11/15/17/23
  • Output Code Type NRZ-L Data/CLK & Internal
  • Bit Error Rate Within 1db to Theoretical
  • Loop Bandwidth Automatic Full Digital
  • Tracking Range Automatic Full Digital
  • Clock Format 0 Degree and 180 Degree
  • Indicators Search & Lock software indicators
  • Operating Temp Better than 0 to 50 deg C
  • Optional error correction

PCI-SD4-2

Features

  • Card Type: PCI PNP, Bus Master DMA no jumpers or switches on the card
  • Transfer Notification: PCI Interrupts on FIFO flip flop
  • Bus Transfer: Speed Burst 80 million words per second
  • Input Types: 4 Serial RS422 or TTL
  • Input Bit Rate: 100 bps to 32 Mbps
  • Input Code Type: NRZ-L BNC & Internal
  • Output Types: 4 Serial RS422 or TTL
  • Output Code Types: NRZ-L/M/S, BIO-L/M/S, DM-M/S,RNRZ/RNRZR-9/11/15/17/23
  • Output Bit Rate: 100 bps to 32 Mbps
  • Maximum I/O Rate: 32 Mbps/Channel (Maximum 80 Mbps/Card)
  • Time IRIG A, B and G
  • BER function available via software option

BSYS4A

Features

  • Card Type: PCI PNP, no jumpers or switches on the card
  • Transfer Type : DMA
  • Input Connector : SMA and BNC, Auto gaining input 20 mV > 10 Vpp
  • Output Level : TTL750 hm and RS422 Switchable, BNC External and Internal
  • Data Polarity : Normal or Inverted
  • Input Bit Rate : 1 Bit/ Sec to 30 MBit/Sec
  • Input Code Types : NRZ-L/M/S, BIO-L/M/S, DM-M/S, RNRZ/RNRZR – 9/11/15/17/23
  • Output code type : NRZ-L BNC & Internal
  • Loop Bandwidth : Digital Fully Automatic
  • Acquisition Ranges : Digital Fully Automatic
  • Tracking Range : Digital Fully Automatic
  • Bit Error Probability : Within 1db to Theoretical
  • Loop Bandwidth : Automatic Fully Digital
  • Tracking Bandwidth : Automatic Fully Digital
  • Clock Format : 0 Degree and 180 Degree
  • Indicators : Search and Lock Software indicators
  • Operation Temp : Better than 0to 50 deg C
  • Storage Temp : Better than -20 to 80 deg C
  • Operating Humidity : 0 to 95% non – Condensing

USB-SD2 BS

Features

  • Card Type Daughter card , no jumpers or switches on the card
  • Transfer Type USB
  • Input Connector SMA and BNC, Auto-gaining input 20mV >10 Vpp
  • Output Level TTL75 Ohm and RS422Switchable, BNC External and Internal
  • Output Level TTL75 Ohm and RS422Switchable, BNC External and Internal
  • Data Polarity Normal or Inverted
  • Input Bit Rate 100 bps up to 20 Mbps
  • Input Code Types NRZ-L/M/S, BIO-L/M/,DM-M/S, RNRZ/RNRZR-9/11/15/17/23
  • Output Code Type NRZ-L Data/CLK & Internal
  • Bit Error Rate Within 1db to Theoretical
  • Loop Bandwidth Automatic Full Digital
  • Tracking Range Automatic Full Digital
  • Clock Format 0 Degree and 180 Degree
  • Indicators Search & Lock software indicators
  • Operating Temp Better than 0 to 50 deg C
  • Storage Temp Better than -20 to 80 deg C
  • Operating Humidity 0 to 95% non-condensing

Ground Based Data Recorders - Permastore

PS2 Recorder

Features

  • Up to 1.5 gigabit per second sustained data transfer rate
  • Up to 16 terabytes of storage in modular increments
  • Network and serial .DOT user equipment interfaces
  • Full IRIG 106 Chapter 10 support
  • Full-duplex user equipment data ports support simultaneous read and write
  • Automatic error monitoring and correction
  • Optional multiple-channel input multiplexer for PCM, ANALOG, VIDEO, ARINC429, MIL-STD-1553B, DISCRETE, UART, IEEE-1394, PARALLEL and ETHERNET
  • Options for both recording and reproduction
  • Extensive built-in-test, diagnostic and status reporting software

Analysis Software

Vusoft

Features

  • Format and Data Decoding of Multiple Streams in Multiple Formats
  • Records Raw and Processed Data
  • Record in IRIG106 Chapter 10 Format
  • Time Alignment of All Data Streams and Displays
  • Over 50 Display Types:
    • Tabular, Alarms, Bar Graphs
    • FFT's, Line Graphs, Strip Charts
    • XY Plots, Digital Filters, Discrete
  • Math Engine for Derived Parameters
  • Encrypted Network Data Distribution
  • Change Parameter Definitions On-The-Fly
  • Client Software with Full Display, Math and Recording Capabilities
  • Post-Processing and Report Generation
  • External and Embedded Time Formats:
    • IRIG-A, B & G, GPS
    • MDBM, MABM, MTCG, Ayden IRIG A & B
    • FMV, TTC, Veda

Common Mission Debrief Program [CMDP]

Features

  • Windows XP & .NET Based
  • 4 Aircraft Playback each with:
    • 4 Video/Audio Channels
    • 16 Mil-Std-1553 Bus Channels
    • 1 PCM Channel (Chapter 4/8)
  • Select Any Video Channel from Any Air-craft into Any Display; On-The-Fly!
  • Auto-Launch with "Hot Debrief"
  • Data Archive & Retrieval Wizard
    • Local-Network Storage or AIT-3 Tape
  • Time Alignment of Video/Audio & Data
  • Variable Speed Replay (from x0.1 to x10)
  • Import Full Bus Database from User Formats
  • Time & Event Export Products:
    • Video/Audio to MPEG-2 Files or Windows Media Files (ASF)
    • Mil-Std-1553 to CSV Files
    • Raw Chapter 10 Files; All or selected channels
  • User Settings & Aircraft/Display Setup Files
  • Full Time Scrolling & Event GoTo Points

Ancillary Equipment

ACU-22 JDA Antenna Control Unit

Features

  • Controls any JDA Systems antenna
  • 15 inch TFT touch screen display with external display output
  • Front panel user positional controls
  • USB for external keyboard and mouse
  • Extensive built-in test, diagnostic and status reporting software
  • 512 gigabytes of solid state internal storage and 3TB USB 3.0 external storage
  • Up to 1.5 gigabit per second sustained data transfer rate
  • Two to Eight channel all band receiver
  • Continuous azimuth movement
  • Two to Eight channel High performance Bit Synchronizer
  • No special ACU hardware needed
  • Two to Eight channel soft decoms
  • 16 to 32 Channel DAC
  • IRIG A, B and G Decoder with time seed and free-wheel feature
  • Advanced decoder, archival, display and analysis software
  • Full IRIG 106 Chapter 10 support
  • Integrated BNC Break Out panel
  • Two to Eight Bit Sync Data Outputs suitable for external devices
  • Two to Eight Data and clock Decom In-puts for Dual Stream Internal Operation

Analog Output

Features

  • The 16 channel Analog output ENET unit which adds up to 16 14 bit programmable analog outputs in the range of 0 -10 V each with an update rates of in excess of 1 kilo sample per channel per second and all that over a standard 100MBit/Sec Ethernet connection.
  • Multiple units may be used in an installation with the limiting factor only being the available Ethernet bandwidth.
  • This unique design offers exceptional flexibility in the placement of the analog output unit to best meet the customer's requirements.
  • He unit may be powered locally or as Power Over Ethernet (POE) and is fully compatible with the JDA Systems VuSoft software
  • It may be integrated into other applications using the available Windows compatible API.

VT – 004 Antenna Radome

Features

  • The VT-004 auto tracking antenna to be placed outside for extended periods JDA Systems offer a light weight composite radome.
  • This protects the antenna for extended, or permanent, installation outside.
  • The dome may be installed or removed in seconds using the two rotary side locking connectors and the dome weighs only a couple of kilograms making it easy to manoeuvre single headedly if required.
  • The slanted observation window offers the integrated antenna camera system a complete free view of the external environment without significant obstruction and the dome is transparent to RF signals with no measurable degradation in the received signal strength or quality of the antenna when installed.

Instrumentation Gateways

iGU – Instrumentation Gateway

Overview

The iGU is a configurable gateway between instrumentation systems and Ethernet networks or telemetry transmitters.

This small self-contained rugged airborne unit, contains a layer 2/3 managed Ethernet switch, powerful FPGA and quad-core ARM CPU which allows unprecedented flexibility in data processing and protocol transforms.

Along with PCM and video inputs/outputs the iGU also contains a hardware based IEEE-1588v2 time engine with in the switch and a 1PPS output from the 1588 time.

Features :

  • PCM & Video Input to Chapter 10 UDP
  • Chapter 10 UDP to HDLC/Chapter 7 PCM Output
  • Any Ethernet Protocol to HDLC/Chapter 7 PCM Outpu
  • IEEE-1588v2 Master/Slave, IRIG TCG

iES-6 – Integrated Ethernet Switch

Overview

The integrated Ethernet Switch (iES-6), is a rugged 6 port layer 2/3 managed gigabit Ethernet switch with end node timing and discrete signal capabilities for demanding test instrumentation environments on airborne, shipboard or mobile ground vehicles

Programmable or data driven discrete outputs can be used to control end node devices on or off the network as well as feedback into the iES-6 from discrete inputs.

With multiple time sources and outputs the iES-6 provides end node device time signals. iES-6 contains a hardware based IEEE-1588v2 time engine able to drive the internal IRIG-A/B/G Time Code Generator (TCG) for time outputs. The IRIG-A/B/G input provides IEEE-1588 Grand Master/Master clock capabilities.

Features :

  • 6 Tri-Speed Ports w/ Layer 2/3 Switch Management
  • IRIG-A/B/G Time Code Generator
  • 1 IRIG DC Input
  • 2 IRIG DC/1PPS Outputs & 2 IRIG AM Outputs
  • Up to 4 IEEE-1588v2 Clocks w/ Grand Master Capability
  • 8 Programmable Discrete Inputs/Output

iES-12 – Integrated Ethernet Switch

Overview

The integrated Ethernet Switch (iES-12), is a rugged 12 port layer 2/3 managed gigabit Ethernet switch with end node timing and discrete signal capabilities for demanding test instrumentation environments on airborne, shipboard or mobile ground vehicles.

A programmable FPGA tied directly into the switch with two 1G interfaces provides packet processing capabilities. Programmable or data driven discrete outputs can be used to control end node devices, on or off the network, as well as feedback into the iES-12 from discrete inputs. The FPGA also provides built-in HDLC & IRIG 106 Chapter 7 PCM encoder & decoder. This allows PCM output of VLAN, mirrored or filtered Ethernet switch traffic or from the PCM input decoded Ethernet back out the switch Ethernet ports.

Features :

  • 12 Tri-Speed Ports with Layer 2/3 Management
  • Switch Connected Programmable FPGA for Packet Level Data Processing
  • HDLC/Chapter 7 PCM Encoder/Decoder
  • GPS Receiver & IRIG-A/B/G Time Code Generator
  • 3 IRIG DC/1PPS Outputs & 3 IRIG AM Outputs
  • Up to 4 IEEE-1588v2 Clocks w/ Grand Master Capability
  • Up to 16 Programmable Discrete Inputs/Outputs

iES-8 – Integrated Ethernet Switch

Overview

The integrated Ethernet Switch (iES-8), is a rugged 8 port layer 2/3 managed gigabit Ethernet switch for demanding environments on airborne, shipboard & ground vehicles.

iES-8 contains a hardware based IEEE-1588v2 time engine with (4) independent clocks which can be setup as ordinary, boundary, peer to peer transparent or end to end transparent, master only, slave only & one or two step clock. The hardware timer in the MAC, provides (20) nanosecond accuracy & (4) nanosecond resolution.

Features :

  • 8 Tri-Speed Ports w/ Layer 2/3 Switch Management
  • Ethernet Switch Traffic Processing & Filtering
  • Up to 4 IEEE-1588v2 Clocks

Recorder/Reproducer Systems

CPAS-5500 MITR – Ruggedized TAP Recorder

Overview

The Modular Instrumentation TAP Recorder (MITR) is a high-bandwidth, high-capacity IRIG 106 Chapter 10 data recorder/ publisher with a TAP Interface Module (TIM) & multiple Tera-Bytes of high-speed removable storage. MITR is suitable for a wide range of data recording requirements in harsh & demanding environments.

Configurable TIM’s provide protocol independent full duplex optical transceivers. Applications include GigE, Fibre Channel, AS5643 IEEE-1394B (Firewire), or any specific communication application. Input channels are recorded/ published & mirrored outputs provide full active TAP capabilities.

Features :

  • Over 12Gbps (1.5GBps) Sustained Record Rate
  • Up to 24TB of RMM Storage Capacity
  • Simultaneous Chapter 10 Streaming up to 4Gbps to Ethernet Ports
  • Frame, Upper Level Protocol, Message/Sub Message Filters
  • HDLC/Chapter 7 PCM Output
  • 4/8/12 Channel DC-10G Optical: Fibre Channel, Ethernet, AS5643 IEEE-1394B, sFPDP, & More
  • 4/8/12 Channel 2G Copper
  • Optical/Copper Mixed Channels

CPAS-5000 DataHUB – Recorder/ Reproducer System

Overview

As part of our Chapter 10 Products, Applications and Solutions (CPAS) family, the CPAS-5000 DataHUB turn’s any PC into a fully compliant IRIG106 Chapter 10 PCM Recorder/Reproducer System by natively creating & decoding PCM and time packet streams

A .NET Windows application, CPAS-5000 DataHUB Control Software (DCS) is provided along with a full API to expand the capabilities of this powerful yet flexible device.

Features :

  • Any PC Can Be a Recorder & Reproducer
  • PCM In, Chapter 10 Out
  • USB Plug-n-Play Device, Completely Self Contained
  • Laboratory, Flightline, Range & Mobile Uses
  • Native IRIG106 Chapter 10 Compliancy – No Format Conversions
  • Chapter 10 UDP Publisher
  • Fully independent PCM/Time Input & Output Channels
  • GPS Receiver & IRIG Time Code Generator
  • High Accuracy ± 1us Time Tagging/Alignment
